Aircraft Specifications
Performance| Endurance | 3 hours |
| Cruise Speed | 85 mph |
| Max Speed | 180 mph |
| Max Ceiling | 10,000 feet |
| Normal Cruise Altitude | 1000 - 5,000 feet |
| Range | 100 miles |
| Takeoff/Landing Speed | 35 mph (STOL-Capable) |
| Max Payload Capacity | 25 lbs total |
| Type | Single Engine, Tractor, V-Tail |
| Engine | 62-150cc Single or Dual Cylinder (gasoline) |
| Construction | Modular, Compression Molded Composite |
| Landing Gear | Fixed Tricycle |
| Wingspan | 8'7" |
| Length | 6'3" |
| Height | 2'9" |
| Weight | 40 lbs (dry/no payload) / 75 lbs (wet/max payload) |
- Gapless flight control surfaces
- Generator (300 watts)
- Trailing Edge Flaps
- LED Navigation & Landing Lights
- Two Wing Payload Stations
- Forward Look Camera (FLC) + EO/IR Pan/Tilt/Zoom Camera
- IR Night Landing System (IRNLS) (optional)
- Centerline Fuselage Payload (15 lbs)
- Wing Payload Stations (2) (optional - 5 lbs each)
- Wing Fuel Tanks (optional)
Operational Capabilities
The GT-380 RPAS is designed to fulfill multi-role applications in the short field takeoff and landing environment. The aircraft incorporates multiple high-lift devices and "all-composite" construction to enable flight operations in confined rural and urban areas.
With the high-lift devices stowed, the specially-designed laminar-flow airfoil allows the GT-380 to cruise in excess of 100 mph, reducing the "base to on-scene" flight time and extending its range. The fixed landing gear includes a rugged shock suspension system and steerable nosewheel, providing a robust capability in rough-field operations. Brakes are optional on the main wheels.
The powerplant is an air-cooled, single or dual cylinder engine. The optional dual cylinder engine can incorporates an electric starter for inflight start and a generator system capable of 300 watts of inflight power. An internal 1 gallon fuel supply and wing station fuel can provide endurance exceeding 3 hours and 100 miles. On-site assembly, launch, and operation are accomplished with only 2 personnel in 30 minutes or less.
NOTE: The GT-380 RPAS completed initial flight testing in July 2015 and final flight testing in April 2016 to validate performance specifications.
